FLAMESHIELD FS240JM

  • BS EN 1634-1

  • BS EN 16034-2014

  • Classification Report – WF422883

  • EXAP to BS 15269-10 - WF422881

  • BS EN 13241 – 2812-CPR-RA5009

  • Masonry and Steel Structure Tested. - WF421972

  • Timber Structure Tested - WF421378

  • CE Marked

Our Flameshield FS240JM, certified for both rigid and flexible apertures, provides fire protection and compartmentation for various types of applications. Fire shutters are essential for ensuring the safety of occupants and limiting the spread of fire damage to a building in the event of a fire emergency. Our Flameshield FS240JM fire shutters are CE Marked, constructed in line with fire testing to BS EN 1634-1 and in full compliance with BS EN 16034:2014.

COMPONENTS

There are a number of standard components and optional extras available for the various control panel types offered by A1S Group for Fire Shutters.

The Motor is built with rapid set limit switches and incorporates a low-level override system with a controlled descent. Each JM motor has a built-in PCB controller and a low-level open/stop/close push button. Open, close and two safety limits as standard. Single or Three Phase Options

Push up down and emergency stop buttons supplied pre wired for easy installation

Design Information

  • Full technical CAD drawings available

  • Formed from 20swg steel sheet, with the top leg slotted for expansion. Dependent on the fire rating of the shutter (1HR, 2HR and 4HR) and the size of the opening.Formed from 20swg steel sheet, with the top leg slotted for expansion. Dependent on the fire rating of the shutter (1HR, 2HR and 4HR) and the size of the opening.

  • The endplates are fixed to a steel fixing angle which spans the full height of the shutter, which in turn is fixed back to the wall construction. Accordingly, the angles are slotted for expansion with an anchor point located at the bottom of the angle.

  • Vary from 50mm straight channel galvanized guide mounted on 75mm x 50mm mild steel angle (minimum). For shutters of increased width, we allow for expansion and the depth of each guide rail shall be increased dependent on the shutter width.

  • Fire shutter barrels are manufactured from mild steel tube, tube size dependent on the overall size of the unit and deflection calculated to conform to British Standards.

  • Fire relay linked to the fire alarm to allow closure from a fire alarm signal comes complete with a battery backup (Mandatory). The fire relay and battery backup are tested as part of the Ability to Release and Durability tests.

    Alternatively, Audio Visuals Panels are available, again to be linked to the fire alarm, this unit offers the facility of a timed delay, these flash and sound to warn that the fire shutter is closing.

  • Industry standard 12 months parts and labour warranty. Excludes damage and misuse by others.

    Terms & Conditions Apply

  • There is a requirement under The Regulatory Reform (Fire Safety) Order 2005 for companies to ensure fire safety equipment is maintained and a record kept.

    Weekly: Check all the system for correct operation

    6 Months: Inspections and test of the systems by a competent engineer

    Annually: Full inspections and testing adjustment, lubrication, repair, and cleaning’ of the systems by a competent engineer.
